Epson EB-570, 2700 ANSI lumens, 3LCD, XGA (1024x768), 10000:1, 4:3, 1422.4 - 2362.2 mm (56 - 93")

V11H605041
EPSV11H605041
UOS: PIECE
Hide
Epson EB-570, 2700 ANSI lumens, 3LCD, XGA (1024x768), 10000:1, 4:3, 1422.4 - 2362.2 mm (56 - 93")
Code: EPSV11H605041
OEM Code: V11H605041
Pack Size: PIECE Minimum Order Quantity: 1
Login To Buy

Overview

Epson EB-570, 2700 ANSI lumens, 3LCD, XGA (1024x768), 10000:1, 4:3, 1422.4 - 2362.2 mm (56 - 93")

Specification

Design
Product colourWhite
Cable lock slot typeKensington
Cable lock slotYes
Display
Colour depth10 bit
Built-in displayNo
Features
HDCPNo
On Screen Display (OSD)Yes
Password protectionYes
Noise level (economic mode)28 dB
Country of originPhilippines
Lens system
Zoom capabilityYes
Zoom typeAuto
FocusManual
Aperture range (F-F)1.8 - 1.8
Focal length range3.71 - 3.71 mm
Zoom ratio1.35:1
Light source
Service life of light source (economic mode)10000 h
Lamp power215 W
Logistics data
Pallet width (UK)100 cm
Pallet gross width80 cm
Products per pallet12 pc(s)
Products per pallet (UK)12 pc(s)
Pallet gross length120 cm
Pallet length (UK)120 cm
Products per pallet layer (UK)2 pc(s)
Products per pallet layer2 pc(s)
Quantity per pack1 pc(s)
Pallet height (UK)2.04 m
Pallet gross height2.04 m
Multimedia
RMS rated power16 W
Built-in speaker(s)Yes
Network
Ethernet LAN data rates10,100 Mbit/s
Wi-FiNo
Ethernet LAN (RJ-45) ports1
Ethernet LANYes
Operational conditions
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)10 - 90%
Operating relative humidity (H-H)20 - 80%
Storage temperature (T-T)-10 - 60 °C
Other features
RS-232 ports1
Packaging content
Cables includedAC
Remote control includedYes
ManualYes
Ports & interfaces
Microphone inYes
PC Audio outYes
USB connector typeUSB Type-A, USB Type-B
PC Audio inYes
S-Video inputs quantity1
Serial interface typeRS-232
Audio (L/R) in0
USB 2.0 ports quantity2
Power
Power consumption (typical)318 W
AC input frequency50 - 60 Hz
AC input voltage220 - 240 V
Power consumption (standby)0.33 W
Power sourceAC
Power consumption (economy mode)230 W
Projector
Matrix size1.4 cm (0.55")
Screen size compatibility1422.4 - 2362.2 mm (56 - 93")
Projection distance (wide)0.4 - 0.4 m
Projection distance (tele)0.6 - 0.6 m
Keystone correction, vertical3°
Keystone correction, horizontal3°
Software
Mac operating systems supportedYes
Windows operating systems supportedYes
Linux operating systems supportedYes
Storage
Card reader integratedNo
Video
Full HDNo
3DNo
Video colour modesBlackboard, Dynamic, Presentation, Sports, sRGB, Theatre, Whiteboard
Weight & dimensions
Height155 mm
Width367 mm
Package weight18.5 kg
Depth375 mm
Package width520 mm
Package depth810 mm
Package height320 mm
