| Design |
| Display number of lines | 3 lines |
| Display | LCD |
| Keyboard layout | QWERTY |
| Display number of characters | 20 |
| Backlight display | Yes |
| Product colour | Black |
| Logistics data |
| Harmonized System (HS) code | 84433210 |
| Master (outer) cases per pallet | 24 pc(s) |
| Pallet gross weight | 243.6 kg |
| Pallet gross height | 16.2 cm |
| Products per pallet | 72 pc(s) |
| Layers per pallet | 4 pc(s) |
| Master (outer) cases per pallet layer | 6 pc(s) |
| Other features |
| Number of frames | 99 |
| Date & time printing | Yes |
| Print preview | Yes |
| Country of origin | China |
| Memory capacity | 2800 characters |
| Packaging content |
| Bundled software | P-touch Editor 5 professional |
| Carrying case | Yes |
| Cables included | USB |
| Starter roll included | Yes |
| Warranty card | Yes |
| Quick start guide | Yes |
| AC adapter included | Yes |
| Packaging data |
| Package type | Box |
| Package weight | 3.4 kg |
| Paper handling |
| Maximum label width | 2.4 cm |
| Autocutter | Yes |
| Performance |
| Underline | Yes |
| Built-in barcodes | 1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, EAN128, EAN13, EAN8, GS1-128, ITF-25, UPC-A, UPC-E |
| Tape cutting | Automatic |
| Number of fonts | 12 |
| Number of symbols | 617 |
| Tape type | TZe |
| Internal memory | 99 MB |
| Image formats supported | BMP, JPG, TIF |
| Number of printing lines (max) | 7 |
| Number of styles | 11 |
| Ports & interfaces |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN | No |
| Wi-Fi | No |
| USB port | Yes |
| Power |
| Auto power off | Yes |
| Battery type | AA |
| Number of batteries supported | 6 |
| Printing |
| Maximum printing width | 2.4 cm |
| Print speed | 30 mm/sec |
| Maximum resolution | 180 x 360 DPI |
| Text alignment | Center, Justify, Left, Right |
| Maximum print height | 1.8 cm |
| Mirror printing | Yes |
| Text style | Bold, Italic, Normal, Shadow |
| Vertical printing | Yes |
| System requirements |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows Vista x64 |
| Weight & dimensions |
| Weight | 2.76 kg |
| Depth | 350 mm |
| Height | 325 mm |
| Width | 150 mm |
